KFI Combo Kit - A3000 Winch & Winch Mount - 2005-2010 Polaris Sportsman 400 500 600 700 800

Brand New "KFI" Winch Mount for the following Polaris ATV's:

• 2005 Polaris Sportsman
  • 400, 500 H.O., 600, 700, 700EFI, 800EFI
• 2006Polaris Sportsman
  • 450, 500 H.O., 500EFI, 700, 700EFI, 800EFI, X2
• 2007Polaris Sportsman
  • 450, 500EFI, 500EFI X2, 700EFI, 800EFI, 800EFI X2
• 2008Polaris Sportsman
  • 500 HO, 500 EFI, 800 EFI HO, 500 EFI X2
  • 700 EFI X2, 500 EFI TOURING, 800 EFI TOURING
• 2009Polaris Sportsman
  • 500 HO, 500 EFI, 800 EFI, 500 EFI X2, 800 EFI X2
  • 500 EFI TOURING, 800 EFI TOURING
  • BIG BOSS 6x6
• 2010Polaris Sportsman
  • 500 HO, 800
  • 500 HO TOURING
  • 800 BIG BOSS 6x6

Will ONLY work with the Polaris Sportsman's that have the front end pictured below:

Designed to work with the following winches:

• KFI: ST17 / A2000 / A2500-R2 / A3000 / SE25 / SE35
• KFI: AS-50  (requires purchase of ATV-MR)
• WARN:A2000 / A2500 / U2500 / 1.5ci / 2.5ci / 2.5ce / 3.0ci / 3.0ce / 3.0s
• WARN:RT15 / RT25 / RT30 / XT15 / XT25 / XT30
• WARN:Vantage 2000-3000lbs / Provantage 2500-3500lbs
• RAMSEY : ATV2500 / ATV3000
• SUPERWINCH : Terra25 / Terra35 / A3500 / LT2000 / LT2500 / LT3000 / LT4000ATV
• MILE MARKER :PE2.5 / PE 3.5 / VMX2.5 / PE2000 / PE3000 / PE2500 / PE3500
• MASTER LOCK :1500lbs #2955AT
  • Requires roller fairlead with a 4.875" bolt pattern; available if needed #ATV-RF.
• CYCLE COUNTRY :Work Power 1500 and 2500 / Powermax 2500, 3500
• BADLAND: 2-Hole Winches (Click Here for Details)
• BADLAND: Standard Winches (Click Here for Details)
• CHAMPION : 2-Hole Winches (Click Here for Details)
• CHAMPION : Standard Winches (Click Here for Details)
• KEEPER CORP. TRAKKER :KT2500 / KT3000 / KT2500C / KT3000C
• KEEPER CORP. TRAKKER :KT2000
  • Requires roller fairlead with a 4.875" bolt pattern; available if needed #ATV-RF.
• SMITTYBILT :XRC 2.0
  • Requires roller fairlead with a 4.875" bolt pattern; available if needed #ATV-RF.
  • Listed models come with incorrect ATV roller fairleads.
• SMITTYBILT :XRC 3.0 / XRC 4.0
• XGEAR:  X3000 / X4000
  • 4-Hole Standard (3.00" x 4.875" bolt pattern)
• VENOM: 2000 / 2500 / 3000 / 3500 / 4000 / 4500 / 5000 (Standard ONLY)
  • 4-Hole Standard 3.00" x 4.875" bolt pattern with rollers that are 4.875" bolt pattern
• Traveller:1078088 / 1078302
  • Requires roller fairlead with a 4.875" bolt pattern; available if needed #ATV-RF
• Possibly many others with the below standard mounting patterns, call to confirm.
  • 4-Hole Standard (3.00" x 4.875" bolt pattern with rollers that are 4.875" bolt pattern)
  • 2-Hole (3.10" with rollers that are 4.875" bolt pattern)
• QUADBOSS: RP25 / RP35

• 100% MADE IN USA.
• Constructed of 10 GA GR50 steel.
• Designed to fit between the headlights as shown in the picture below.
• Unlike all other mount competitors our mounts are metal bead blasted before they are powder coated for the best possible finish prep.
• Powder coated black for supreme durability.
• Mounts the same as OEM intended.
• Includes bumper access cover cut-out patterns.
• Works with all Polaris OEM Brush Guards and Double Tube Bumpers.
• Very easy to install.
• Complete installation instructions included.
• All mounting hardware included.
• Satisfaction guaranteed.
• Roller fairlead and winch not included.

Why buy the OEM Kit when you can  SAVE $100-$150 by getting your Winch separate and buying our High Quality 100% American made winch mount.  Your Sportsman is pre-wired with the battery wires pre-ran from your battery to the contactor mount located under your front RH wheel well.  We have everything you need in our kit to mount your winch and fairlead.

(Picture shown of ATV does not show the access cover re-assembled with the cut-out option)

Winch Details:
Whether its on a winding trail, plowing snow or deep in the mud, a reliable winch is the most important accessory a rider can have.  Equip your ATV, UTV or SxS with a KFI WINCH and feel confident you can pull yourself out of any situation.  This 3000lb ATV Series winch features quality cast aluminum and durable steel components, water resistant seals to keep the elements out, a standard 4-hole mounting design and a heavy duty all metal turn clutch.  It is also backed by a "KFI 1-Year Limited Warranty".  The KFI A3000 winch comes with everything you need other than an ATV model specific winch mount.  Everything shown is included along with detailed installation instructions and hardware to mount your winch to a model specific ATV winch mount.

Winch Includes:

Take control of your winch with the included Mini-Rocker Switch. It comes with an adjustable bracket to mount on to your ATV's handlebars. This allows you to control your winch with just the touch of your finger, never having to let go of your handlebars.


Also included is a Handheld 14' CordedRemote for those situations when you need to control your winch from a distance ordismounted from your machine. This compact high quality remote offers a more reliable control than the other wireless options. Included is a socket plug and play wiring system so that you can store your remote when not in use.


The included Heavy Duty Electric Contactor protects your ATV's electrical system and switches the power distribution of your winch that is controlled from your switches.
