KFI #106745 Quick Plow Pulley – Synthetic Cable | Direct Replacement for #106270

OVERVIEW

The KFI #106745 Quick Plow Pulley is engineered to streamline seasonal plow setup by replacing the standard winch fairlead with a dedicated lifting component built for synthetic winch cables. Constructed with a large aluminum wheel and quick-attach mounting hardware, this pulley assembly optimizes lift geometry and maintains precise cable alignment on KFI UTV and ATV snow plow systems. It delivers controlled blade operation while actively protecting synthetic lines from flattening or kinking during heavy winter service.

ENGINEERING & PERFORMANCE

Rerouting cable travel through this pulley corrects lift angles, which stabilizes plow tracking and significantly reduces cable vibration under heavy loads. The 2-1/8-inch aluminum wheel rides inside a curved guide groove that prevents edge wear and stops synthetic rope from collapsing or developing weak spots. A stationary wheel configuration removes the pinch points common on traditional fairleads, while multi-position bolt holes let operators dial in exact cable tension for their specific push-tube length. The rapid-swap mounting design cuts down seasonal installation time without sacrificing rigid performance in freezing temperatures.

KEY FEATURES

• Direct replacement for KFI #106270 standard winch fairlead
• Engineered exclusively for synthetic winch cable systems
• Large 2-1/8-inch aluminum wheel for low-friction cable travel
• Curved channel groove blocks cable flattening and premature fiber fatigue
• Stationary wheel architecture prevents synthetic line pinching
• Quick on-off bracket enables fast seasonal installation and removal
• Multi-position mounting holes allow precise cable-angle tuning
• Supports both fairlead-mounted and push-tube-mounted configurations
• Aligns lift forces for smoother, more controlled blade raising
• Maintains proper cable tracking throughout full plow travel

TECHNICAL SPECIFICATIONS

• Brand: KFI
• Part Name: #106745 Quick Plow Pulley
• Accessory Type: Synthetic Cable Lift Pulley / Fairlead Replacement
• Material: 2-1/8-inch Aluminum Wheel with Curved Guide Groove
• Supported Years: Seasonal winter plow applications
• Compatible Trims or Plow Systems: Standard 4.875-inch bolt-up winches; KFI UTV push tubes #106300 / #106310 / #105635; KFI ATV push tube #105000

FITMENT

• KFI UTV push tubes #106300 / #106310 / #105635
• KFI ATV push tube #105000 (typically not required)
• Standard metric winches with 4.875-inch bolt-up pattern
• Fairlead-mounted or push-tube-mounted plow installations

WHY RIDERS CHOOSE THIS

Plow operators select the #106745 because it converts a generic fairlead into a purpose-driven lifting component that actively guards synthetic cable against heat buildup and crushing. The oversized aluminum drum paired with the curved channel design keeps rope tracking consistently centered, which translates to quiet lift cycles and predictable blade positioning even in packed snow. The adjustable mounting points and quick-release brackets give riders full control over cable tension and seasonal swap timing. By matching lift geometry precisely to KFI plow frames, this pulley extends synthetic line lifespan and keeps UTV and ATV plow rigs working reliably all winter long.
