KFI Mid‑Mount Snow Plow Mount – Arctic Cat & Suzuki ATV Models (02–25) Fits 105000 Push Tubes

OVERVIEW

This KFI mid‑mount snow plow mount delivers a reinforced attachment architecture that stabilizes blade tracking and reduces frame fatigue during heavy snow removal. Fabricated from 3⁄16‑inch and 1⁄4‑inch Grade 50 steel with a durable black powder‑coat finish, the bracket securely interfaces with KFI 105000 ATV push tubes. The unit provides model‑specific mounting geometry for a rigid, vibration‑free connection on compatible Arctic Cat and Suzuki utility ATVs.

ENGINEERING & PERFORMANCE

The reinforced steel housing maintains precise alignment under lateral loading, allowing the plow to track smoothly through deep drifts without flexing or binding. Grade 50 structural components absorb repeated impact and torsional stress while the bead‑blasted surface ensures the powder coating adheres tightly to resist chipping, abrasion, and winter road salts. Model‑specific mounting layouts align directly with factory hard points, and the pre‑matched pin specifications complete the setup for immediate field deployment.

KEY FEATURES

• Mid‑mount snow plow bracket designed for direct integration with KFI 105000 push tubes
• Constructed from 3⁄16‑inch and 1⁄4‑inch Grade 50 structural steel
• 100 percent made in the USA with controlled machining tolerances
• Metal bead‑blasted prior to application for long‑lasting powder‑coat adhesion
• Engineered for a 14.50‑inch pin‑up width with a standard 3⁄8‑inch clevis pin
• Model‑specific mounting pattern eliminates fabrication or drilling on compatible ATVs
• All required mounting hardware included for rapid installation
• Complete step‑by‑step installation instructions packaged with each unit

TECHNICAL SPECIFICATIONS

• Brand: KFI
• Part Name: Mid‑Mount Snow Plow Mount
• Accessory Type: Mid‑Mount Plow Bracket
• Material: 3⁄16″ & 1⁄4″ Grade 50 Steel
• Supported Years: 2002–2025
• Compatible Trims/Systems: KFI 105000 Push Tubes — Arctic Cat 375‒700 Series & Suzuki Eiger, King Quad 400, Vinson 500, Quad Runner 500

FITMENT

• Suzuki Eiger 400 2x4 / 4x4 (2002–2007)
• Suzuki King Quad 400 AS / AF / ASi / AFi (2008–2025)
• Suzuki Quad Runner LTF 500 4x4 (1998–2002)
• Suzuki Vinson 500 4x4 (2002–2007)
• Arctic Cat 1000 4x4 (2008–2017)
• Arctic Cat 1000 TRV 4x4 (2009–2016)
• Arctic Cat 375 2x4 / 4x4 (2002)
• Arctic Cat 400 2x4 / 4x4 (2002–2008)
• Arctic Cat 400 TBX 4x4 (2005–2006)
• Arctic Cat 400 TRV 4x4 (2006–2014)
• Arctic Cat 450 4x4 (2010–2012)
• Arctic Cat 450 TRV 4x4 (2011–2015)
• Arctic Cat 500 2x4 / 4x4 (2002–2017)
• Arctic Cat 500 TBX 4x4 (2002–2006)
• Arctic Cat 500 TRV 4x4 (2003–2015)
• Arctic Cat 550 4x4 (2009–2014)
• Arctic Cat 550 TRV 4x4 (2009–2016)
• Arctic Cat 650 4x4 (2004–2012)
• Arctic Cat 650 TBX 4x4 (2007–2009)
• Arctic Cat 650 TRV 4x4 (2007–2009)
• Arctic Cat 700 4x4 (2006–2017)
• Arctic Cat 700 Alterra TBX 4x4 (2017–2020)
• Arctic Cat 700 Alterra VLX 4x4 (2018)
• Arctic Cat 700 TBX 4x4 (2010–2017)
• Arctic Cat 700 TRV 4x4 (2008–2016)
• Arctic Cat 700 VLX (2017)

WHY RIDERS CHOOSE THIS

Operators select this mid‑mount bracket because the Grade 50 steel core resists bending when pushing packed snow or clearing icy trails. The bead‑blasted surface and thick powder finish shield against road salt corrosion and gravel abrasion throughout demanding winter seasons. Precision‑cut mounting holes match factory hard points exactly, while the included hardware and detailed instructions eliminate measurement errors and speed up field builds. Riders notice steadier blade height retention and predictable steering response when the mount is integrated with the compatible KFI 105000 push tube system.
